Worm gear fire signal butterfly valve (clip type)

product manual CCC certificate Inspection Report

1.Description

ZSXF signal butterfly valve is one of the accessory accessories in the automatic sprinkler system. As the water source handling control valve of the automatic sprinkler system, it has a valve position display signal, which can be connected to the control center for real-time monitoring, so as to avoid false alarm and improve. System reliability. It is the control valve for the fire water supply and drainage pipeline.

Product standard: GB5135.6 "Automatic sprinkler system Part 6: General purpose valve"

Design Specification: GB50084 "Design Specification for Automatic Sprinkler System"

Acceptance specification: GB50261 "Code for construction and acceptance of automatic sprinkler system"

2. Main technical parameters:

(1) Working medium: water, oil, gas

(2) Maximum working pressure: 1.6MPa

(3) Test pressure: 3.2MPa

(4) Adapt to the ambient temperature: 4 ° C ~ 70 ° C

(5) Operation mode: worm gear type

(6) Switching capacity: DC24V 0.5A; AC220V 1A

(7) Connection method: clip connection

(8) Electrical connection: common line - red; normally open contact - blue; normally closed contact - black

3、Model specifications and dimensions

Model	Nominal diameter	D（mm）	d（mm）	H（mm）	B（mm）	L（mm）	H1（mm）	L1（mm）
ZSXF-50-D	DN50	Φ125	Φ145	255	46	150	238	252
ZSXF-65-D	DN65	Φ145	Φ145	300	50	150	250	252
ZSXF-80-D	DN80	Φ160	Φ145	305	50	150	274	252
ZSXF-100-D	DN100	Φ180	Φ145	320	56	150	304	252
ZSXF-125-D	DN125	Φ210	Φ145	370	58	150	333	252
ZSXF-150-D	DN150	Φ240	Φ145	400	59	150	360	252
ZSXF-200-D	DN200	Φ295	Φ280	465	64	200	/	/
